The ITRON Electronic Correction Instrument refers to an electronic correction instrument used under the condition of a DC power supply. It is a voltage and current signal generator. This device can independently adjust the amplitude of voltage and current as well as the phase difference between them.

The device also includes a standard instrument that can accurately measure voltage, current, frequency, and the virtual power synthesized from voltage and current. Using the readings from the standard meter as a comparison benchmark, it achieves calibration and verification of various measuring devices/systems with variable frequency electrical quantities as the main measurement object. As a standard measuring instrument, its metrological characteristics must comply with the requirements of relevant metrology standards. PowerITRON Electronic Correction InstrumentIt mainly uses digital electronic technology and can provide voltage and current outputs of up to 10kV and 1000A, with a basic accuracy of 0.05%. The amplitude, frequency, and phase angle of voltage and current can be independently adjusted.

In addition to sine wave voltage and current, it can also provide precise voltage output and harmonic distorted current output. All the first 100 harmonics can be independently set by the user, and the amplitude and phase of each harmonic can be independently controlled by the user. The addition of harmonics will not significantly weaken the accuracy or traceability of the measurement. PowerITRON Electronic Correction InstrumentIt can ensure the required output voltage and current even under heavy load. The voltage channel can provide a driving current of 50mA at 10kV output, and the current channel can provide an output voltage of 3V at 1000A output. This is particularly important when testing multiple devices simultaneously to improve work efficiency. Additionally, it is crucial when connecting remote power sources and test stations where the required voltage and current cannot be provided due to cable effects.

This ITRON Electronic Correction Instrument is suitable for electrical measurements, thermal engineering, remote control, scheduling, and other power departments and enterprises that require measurement, detection, and high-precision standard signal sources in power systems, as well as other occasions that require high-precision standard signal sources for measurement and detection. To better use the ITRON Electronic Correction Instrument, here are some precautions for using the ITRON Electronic Correction Instrument.

1. When outputting voltage and current, do not turn off the power, especially when outputting high voltage and large current. Please first turn off the signal output through the software, and then turn off the instrument power.

2. Voltage output should not be short-circuited, and current output should not be open-circuited; before starting the output voltage and current source, the operator should ensure that the external wiring is correct. The wiring part should not be exposed. Please turn off the source output when temporarily leaving.

3. When using this device, please ensure that the device is well grounded, otherwise it may affect the indicator lights.

4. Preheat the device for 30 minutes before measurement or calibration.

5. Do not open the instrument without authorization. There is high voltage inside to prevent electric shock.

The above are precautions for using the ITRON Electronic Correction Instrument. If you want to know more about the ITRON Electronic Correction Instrument, please continue to follow our website!
